The Sperry S-1 bombsight was designed by Elmer Sperry, Carl Norden's former employer. It had several distinctions from the Norden, and some advantages. The Sperry gyroscopes spun at 24,000 rpm, compared to the Norden gyros which ran at approximately 8,000 rpm. This higher rate of rotation overcame the tendency to precess, so there was no leveling mechanism needed, or a requirement for leveling bubbles. In addition, the gyros ran off of induction rather than brushes; the carbon brushes in the Norden gyros tended to produce dust which fouled the bearings.
The Sperry ran off of 110V AC current compared to the 26V DC current used by the Norden. Whereas the Norden had all of its controls mounted on the right, the Sperry had the knobs for range located on the left and for azimuth located on the right, so that the bombardier could use both hands to adjust them simultaneously. The Norden used a manual geared system to correct for crosswind and drift, but the Sperry did this electromechanically.
Norden Bombsight Manual Pdf Viewer
The Navy would not allow the Norden to be exported, but did allow the Sperry to go to other countries such as England. The B-24 Liberator was being sent overseas (as the LB-30), and the Sperry was allowed to go with it. This led to a natural pairing of the S-1 and B-24, so almost all of the Sperry S-1's were in B-24 's. Approximately 5,000 S-1's were made, but the Norden dominated the bombsight market, and production of the S-1 ceased in 1943. Here is a video of what I believe to be is the only working Sperry S-1 in existence. The video seems long, but the second half is a tutorial on the bombing problem and solution:
